Product introduction
MF - II square pulse bag filter is modified on the basis of MF - I type.
Performance characteristics
In addition to the characteristics of high dust removal efficiency, large processing air volume, stable performance, convenient operation and maintenance, it also has the advantages of better use effect, less dust accumulation and wide application range than Type I.
Applicable materials
It is widely used for ventilation and dust removal and dust recovery in grain and food, feed, metallurgy and chemical industry, building materials, medicine and other industries.
| Parameter | Model | ||||||
| MF48 | MF60 | MF72 | MF84 | MF96 | MF108 | MF120 | |
| Filter area（m²） | 36.2 | 45.2 | 54.3 | 63.3 | 72.4 | 81.4 | 90.5 |
| Number of filter bags(only) | 48 | 60 | 72 | 84 | 96 | 108 | 120 |
| Filtered air volume(m³/h) | 6510-8680 | 8130-10840 | 9770-13000 | 11400-1520 | 13000-17370 | 14650-19530 | 16290-21700 |
| Number of solenoid valves(only) | 8 | 10 | 12 | 14 | 16 | 18 | 20 |
| Motive power(kw) | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | 2.2 | 2.2 |
| Filter bag specification(mm) | 120×2000 | ||||||
| Filtration velocity(m/min) | 3-4 | ||||||
| Air leakage rate(%) | ≤5 | ||||||
| Injection pressure(MPa) | ＞0.4-0.6 | ||||||
| Equipment resistance(Pa) | ＜1200 | ||||||
| Dust removal efficiency(%) | ≥99.9（Select appropriate filter media according to dust characteristics） | ||||||
| Parameter | 型号 | ||||||
| MF48 | MF60 | MF72 | MF84 | MF96 | MF108 | MF120 | |
| A | 3530 | 3530 | 3530 | 3530 | 3530 | 3530 | 3530 |
| B | 3287 | 3287 | 3287 | 3287 | 3287 | 3287 | 3287 |
| C | 2552 | 2552 | 2552 | 2552 | 2552 | 2552 | 2552 |
| D | 1160 | 2260 | 1160 | 1160 | 1160 | 1160 | 1160 |
| E | 1350 | 1650 | 1950 | 2250 | 1350 | 2850 | 3150 |
| F | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 | 1350 |
| G | 635 | 635 | 635 | 635 | 635 | 635 | 635 |
| H | 325 | 475 | 625 | 775 | 925 | 1075 | 1225 |
| I | 1586 | 1586 | 1586 | 1586 | 1586 | 1586 | 1586 |
| J | 790 | 790 | 790 | 790 | 850 | 850 | 850 |
| K | 824 | 824 | 824 | 824 | 824 | 824 | 824 |
| M×N | 400×500 | 500×500 | 600×500 | 700×600 | 700×600 | 800×600 | 800×600 |
| P×Q | 432×530 | 530×530 | 630×530 | 728×630 | 728×630 | 832×630 | 832×630 |
| R×S | 1050×1050 | 1350×1050 | 1650×1050 | 1950×1050 | 2250×1050 | 2250×1050 | 2850×1050 |
